applications: Prct Description
Raymo plastic push pull connectors RM-P series
| Part No. |
Good Description |
| RM-PKG-1PC-302KSG PKG.M0.2LLG |
plastic pushl pull connector, panel mount socket, 2pin female contact, for Edan Fetal monitor, ECG monitor
Can mounted in device both from front side and rear mounted
|
Below is the shell size and contact RAYMO have for plastic circular connector :
| Plastic Circular Push Pull connector RM-p series |
| Series |
IP |
Shell Size |
Contacts No. with solder & PCB type |
| RM-P |
40 |
1P /Redel |
2 |
3 |
4 |
5 |
6 |
7 |
8 |
9 |
10 |
12 |
14
|
SHENZHEN RAYMO ELECTRONICS TECHNOLOGY LIMITED
is a manufacturer located in Shenzhen, focusing on manufacturing Creative customer-oriented metal and plastic circular push-pull self-latching connectors and cable assemblies to serve over 75 countries and regions since 2010. Our prcts got very popular recommendation among our customers .
For this plastic connectors, the mail features is listed below :
| Main Feature |
| Secure Push-pull Self-locking system |
| High density assembly to save space. |
| Alignment Key and Polarized Keying System to avoid cross-interface. |
| Colorful plug round nut and socket screw nut for choice, easy for identify |
|
Available solder and PCB or right angle PCB contact.
|
| Technical Characteristics |
| Temperature Range |
- 40° C, +150° C |
Resistance to vibrations |
15 g [10 Hz - 2000 Hz] |
| Shock Resistance |
100 g [ 6 ms] |
Salt spray corrosion test |
>96hr |
| Climatical Category |
50/175/21 |
Shielding (min) |
> 75 dB [ at 10 MHz]
> 40 dB [ at 1 GHz]
|
| IP Rating |
IP 40 |
Certifications |
ISO9001 CE ROHS2.0 SGS
|
Application
Medical, Automotive, Audio-video, Aviation, Communications, Industrial Control, Information Systems, and Machines, Medical, Military, Test and Measurement, Data Acquisition, Data Transfer Equipment. Mle Power, Sensor,Sensor Systems Instrumentation, Analysis Application.
Panel mount receptacle , RM-P PKG type socket Prcts Photo, Shell size and Dimension
FAQ
1. Are your company a professional manufacturer?
Raymo: Yes, we specialized in prcing Circular Connectors and cable assembly since 2010.Our factory is SGS audited manufacturer and worked on www.alibaba.com more than 9 years.
2. What is the MOQ?
Raymo: No MOQ limited, small order is accepted, all is depend on customer real needs.
3. Free sample ?
Raymo: Available. Any needs, please contact us.
4. What about the lead time?
Raymo: sample for 3-5 working days, mass prction for 5-7 working days.
5. What is your payment terms?
Raymo: 100% T/T prepayment when customer place order .
6. Does your prct have any warranty?
Raymo: Yes, all of our connectors can work normally after 5000 cycles mating; our factory has instruments to tested them before shipping. Damage due to misuse, treatment and unauthorized modifications and repairs are not covered by our warranty
