360° EMC 316 CLAD FGG 1B Circular Push Pull Connectors

360° EMC 316 CLAD FGG 1B Circular Push Pull Connectors
360° EMC 316 CLAD FGG 1B Circular Push Pull Connectors 360° EMC 316 CLAD FGG 1B Circular Push Pull Connectors 360° EMC 316 CLAD FGG 1B Circular Push Pull Connectors
اطلاعات پایه
محل منبع: شنژن ، چین
نام تجاری: RAYMO
گواهی: RoHS2.0, ISO:9001-2015, CE , SGS, REACH
شماره مدل: rm-fgg.1b.316.clad
مقدار حداقل تعداد سفارش: 1 قطعه
قیمت: negotiable
جزئیات بسته بندی: 100pc/ctn
زمان تحویل: 5-7 روز کاری
شرایط پرداخت: Western Union ، T/T ، D/P ، D/A ، L/C ، MoneyGram
قابلیت ارائه: 5000تکه/هفته
اکنون تماس بگیرید
نام PRCT: کانکتور کشش را فشار دهید نوع: شاخه کابل نر
اندازه پوسته: 1B شماره تماس.: 16 پین
پایانه: لحیم کردن رتبه بندی IP: IP50
حداکثر جفت گیری: 5000 محفظه: برنج
برجسته کردن:

1B Circular Push Pull Connectors,FGG Circular Push Pull Connectors,360° EMC Circular Power Connector

,

FGG Circular Push Pull Connectors

,

360° EMC Circular Power Connector

FGG.1B.316.CLAD Plug Male Female Solder Circular Push Pull Connectors





100% compatible with LEMO original FGG.1B.316.CLAD



RAYMO P/N LEMO P/N
RM-FGG-0BC-304-JS42Z FGG.0B.304.CLAD42Z

RM-B series metal circular push pull connector with below features:



  • Secure high performance push-pull self-locking system
  • High pin density contributing to equipment miniaturization
  • Alignment Key and Polarized Keying System to avoid cross-interface
  • 360° EMC shielding
  • Robust and shock resistant designs
  • Functional in a wide temperature range from -50°C to +250°C
  • Available solder, PCB and right angle PCB contact
Shell size Contacts no. With Solder & PCB type
00 2 3 4 　 　 　 　 　 　 　 　 　 　 　
0B 2 3 4 5 6 7 9 　 　 　 　 　 　 　
1B 2 3 4 5 6 7 8 10 12 14 16 　 　 　
2B 2 3 4 5 6 7 8 10 12 14 16 19 26 　
3B 3 4 7 8 10 12 14 16 18 21 30 　 　 　



Technical Characteristics
Temperature Range
-55°C, +250°C
Resistance to vibrations
15 g [10 Hz - 2000 Hz]
Shock Resistance
100 g [ 6 ms]
Salt spray corrosion test
>96hrs
Climatical Category
50/175/21
Humidity
Up to 95% at 60°C
IP Rating
IP50
Certifications
ISO9001/ CE/ ROHS2.0/ SGS



Applications of Circular Push Pull Connectors

RAYMO connectors have been widely used in the areas of telecommunication, electronics, medical equipments, aviation, audio-video, petroleum, motor and power industries, electrical signal connection, IC control systems, test and measurement instruments, ect.



Our Advantages

Our company

Raymo company specilized in many kinds of alternative connector such as LEMO, REDEL, , FISHCER, HIROSE, BINDER..., all our connectors can work with original well, since 2010, we keep improving our technic and offer customer with high quality prcts, for the return, we have got many good feekbacks and build a long-term and stable cooperationship.



FAQ

Q1. What is your terms of packing?
A: Generally, we pack our goods in PE bag and brown cartons.
OEM&ODM is available after getting your authorization letters.
Q2. What is your terms of payment?
A: T/T 100% or Alibaba on-line order are both OK.
Q3. How about your delivery time?
A: Generally, it will take 5~7 working days after receiving your advance payment.
Q4. Can you prce according to the samples?
A: Yes, we can prce by your samples or technical drawings. We can build the molds and fixtures.
Q5. What is your sample policy?
A: We can supply the sample if we have ready parts in stock, but the customers have to pay the sample cost and the courier cost.
Q6. Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery.
Q7: How do you make our business long-term and good relationship?
A:1. We keep good quality and competitive price to ensure our customers benefit ;
2. We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from.
