خانه محصولاتاتصالات مدور نظامیPractical 5000 Times Military Electrical Connectors Male Female

Practical 5000 Times Military Electrical Connectors Male Female

Practical 5000 Times Military Electrical Connectors Male Female
Practical 5000 Times Military Electrical Connectors Male Female
Practical 5000 Times Military Electrical Connectors Male Female
اطلاعات پایه
محل منبع: شنژن ، چین
نام تجاری: RAYMO
گواهی: ROHS CE SGS ISO:9001-2015
شماره مدل: RM-FG2-0U1S-P13KS
مقدار حداقل تعداد سفارش: 1 قطعه/قطعه
قیمت: negotiable
جزئیات بسته بندی: کیسه پلاستیکی و کارتن
زمان تحویل: 5-7 روز کاری
شرایط پرداخت: T/T، L/C، T/T، Western Union
قابلیت ارائه: 5000تکه/هفته
اکنون تماس بگیرید
نام PRCT: کانکتور ultimatel ضد آب اندازه پوسته: 0u (= 07) ، 1U (= 08)
جنس: مرد، زن شماره تماس.: 2-14 پین
عایق: PPS ، Peek استقامت: 5000 بار
رتبه بندی IP: IP68 ضد آب نوع تماس: لحیم/PCB مستقیم/90 درجه PCB
مواد تماس: برنج با روکش طلا کابل مونتاژ شده یا نه: بله
برجسته کردن:

SGS Military Electrical Connectors,IP68 Military Electrical Connectors,SGS Military Cable Connectors

,

IP68 Military Electrical Connectors

,

SGS Military Cable Connectors

Practical 5000 Times Military Electrical Connectors Male Female



Simple Practical Military Circular Connectors Cost Effective Good Sealing Performance



Prct Description

RM-U Series   Ultimate series IP68 waterproof Metal circular push pull connectors

Part No.:

UR02L07M010SBK1 / RM-FG2-0U1S-P13KS

Prct Description:

0U(=07) size cable mount push pull connector, FG2 model panle mounted socket, 13pin female contact, code 1, gun-color chrome plated shell in brass



Waterproof Push pull locking metal connector U-series connector, cable to cable connector, free socket, inline connector

Main Futures

1

Secure high performance IP68 waterproof push-pull Self-locking system

2

can be 100% compatible with original Fischer connector

3

can be with different code, code 1,2,3

4

360 angle screening for full EMC shielding.

5

Available solder and PCB or right angle PCB contact.

6

can plated with white or black chrome.

7

SO:9001-2015, CE ,RoHS2.0, SGS, Reach







Technical Characteristics

Temperature Range

- 65° C, +200° C

Resistance to vibrations

15 g [10 Hz - 2000 Hz]

Shell Material

Brass with chrome plated

Humidity

up to 95% at 60° C/140F

Shock Resistance

100 g [ 6 ms]

Salt spray corrosion test

>144 hr

Climatical Category

50/175/21

Shielding (min)

> 95 dB [ at 10 MHz],    > 80 dB [ at 1 GHz]

IP Rating

IP 68

Endurance(shell)

≥5000 mating cycles



Practical 5000 Times Military Electrical Connectors Male Female 0

















Shell size

Contacts no. ( Both with Solder & PCB type )

0U(=07)

2

3

4

5

7

9

10

13

　

　

　

1U(=08)

2

3

4

5

6

7

8

10

12

14





Our Company

SHENZHEN RAYMO ELECTRONICS TECHNOLOGY LIMITED is a manufacturer located in Shenzhen, focusing on manufacturing Creative customer-oriented circular push pull connector and cable assemblies to serve over 75 countries and regions since 2010. Our prcts got very popular recommendation among our customers



RAYMO's high quality connectors are found in a variety of challenging applications and environments including:

Automotive, Audio-video, Aviation, Communications, Industrial Control, Information Systems, and Machines, Medical, Military, Test and Measurement, Data Acquisition, Data Transfer Equipment. Mle Power, Sensor,Sensor Systems Instrumentation, Analysis Application.



Our Exhibition





2020.11

Electronica Munich, Germany

2019 9.24-9.26

Testing Expo, Shanghai

2018 11.12-11.15

Electronica Munich, Germany

2017 9.11-9.16

NAB Show,Netherlands

2016 4.11-4.15

HK Fair

2015 10.2-10.7

ICEEB, Brasil

2014 10.11-10.15

HK Fair

2014 4.11-4.15

HK Fair



Why Choose US?

If you couldn't find exact items you want,PLS kindly email us exact models you need, best price & each model specification details will be provided to you soon. Solve the original brand's high cost and long lead time!
