Shockproof Circular Push Pull Connectors G Coded Self Latching Mechanism

Alternative 0B Series Cable Plug FGG.0B.303.CLAD40Z Lemo Push Pull Connector

The cable mount connectors feature a unique push pull self-latching mechanism for safe and secure mating. The industrial circular connectors are G coded for higher contact density and prevent contact miss alignment with similar connectors.

Self-Latching Connection System for Push Pull Connector

The self-latching system is simple and effective retention solution, providing complete protection against vibration, shock or any pull on the cable.

Engaging the system for Push Pull Connector

To initiate the self-latching system the plug is simply pushed axially into its mating half. Once firmly latched in place via the internal latches the connection is virtually impossible to break. No amount of pulling on the cable or any other part of the connector body will release the two parts.

Techinical characteristics for FGG.0B.303.CLAD40Z Push Pull Connector

Features and Benefits for FGG.0B.303.CLAD40Z Push Pull Connector

• Compact profile for high-density applications
• Unique push-pull latching system for secure mating
• Vibration and shockproof
• 360° shielding for full EMC screening
• IP50 ingress protection
• G coded for higher contact density
• Solder termination
• Gold plated brass contacts
• Cable collets, strain relief and dust caps for extra protection available separately


Applications for FGG.0B.303.CLAD40Z Push Pull Connector

Due to the 0B series compact size, the shielded connectors are ideal for applications in the industrial electronics sector. Some of the most common areas are:

• Test and measurement equipment
• Sensors and actuators
• Instrumentation
• Medical devices
• Audio / video

Part Section Showing Internal Components for Push Pull Connector
