خانه محصولاتاتصالات فشاری چرخشی دایره‌ایFischer Dke Circular Push Pull Conenctors 102 103 104 Shell IP68 Circular Connectors

Fischer Dke Circular Push Pull Conenctors 102 103 104 Shell IP68 Circular Connectors

Fischer Dke Circular Push Pull Conenctors 102 103 104 Shell IP68 Circular Connectors
Fischer Dke Circular Push Pull Conenctors 102 103 104 Shell IP68 Circular Connectors
Fischer Dke Circular Push Pull Conenctors 102 103 104 Shell IP68 Circular Connectors Fischer Dke Circular Push Pull Conenctors 102 103 104 Shell IP68 Circular Connectors Fischer Dke Circular Push Pull Conenctors 102 103 104 Shell IP68 Circular Connectors
اطلاعات پایه
محل منبع: چین
نام تجاری: RAYMO
گواهی: CE/ROHS/REACH/SGS/ISO9001
شماره مدل: RM-DKE-2F1C-P11KS
مقدار حداقل تعداد سفارش: 1 عدد
قیمت: 4.5-14.5
جزئیات بسته بندی: کیف و کارتن PE
زمان تحویل: 5-7 روز کاری
شرایط پرداخت: L/C ، D/A ، D/P ، T/T ، Western Union ، MoneyGram
قابلیت ارائه: 50000 قطعه در ماه
اکنون تماس بگیرید
نوع: فشار کشيد وصل کننده هاي دايره اي جنس: مخاطبین لحیم کاری زن
کاربرد: خودرو رنگ: رنگ طبیعی
عایق: PPS/PEEK ماده پوسته: برنج
استقامت: 5000 چرخه رتبه بندی IP: IP68
برجسته کردن:

Fischer Dke Circular Push Pull Conenctors,PEEK IP68 Circular Connectors,104 Shell IP68 Circular Connectors

,

PEEK IP68 Circular Connectors

,

104 Shell IP68 Circular Connectors

Fischer DKE Circular Push Pull Conenctors 102 103 104 Shell

Raymo DKE circular push pull connector brief intrction

Raymo Connectors’ original push-pull automatic locking is widely adopted by the industry for its ease of use, safety of mating and speed in connection and disconnection.
  1. Fully secured against accidental disconnection, it provides unparalleled signal integrity.
  2. ntegrated into the connector housing, it is ideal for compact prct design
  3. Connectors are compatible with Fischer cores connectors
Raymo DKE circular push pull connector characteristic
  1. Secure high performance push pull self-locking system
  2. Sealed up to lP68 and hermetic
  3. 3 codes alignment key and polarized keying system to avoid cross-interface
  4. 360°EMC shielded
  5. High pin density contributing to equipment miniaturization
  6. Robust and shock resistant designs
  7. Functional in a wide temperature range from -50°C to +250°C
  8. Available solder,PCB and right angle PCB contact
Raymo DKE circular push pull connector specification



RM-F Series Circular Push Pull Connector
Shell size 0F(102). 1F(103), AF(1031),2F(104),3F(105) Contact No. 2,3,4,5,6,7,8,9,10,12,14,16,19
Shell model Straight plug FGG MOQ 1pc
Gender Male, Female Free Sample available
Endurance 5000 mating cycles IP Level IP68

Technical Characteristics
Temperature Range - 40° C, +200° C Resistance to vibrations 15 g [10 Hz - 2000 Hz]
Shock Resistance 100 g [ 6 ms] Salt spray corrosion test >96hr
Climatical Category 50/175/21 Shielding (min) > 75 dB [ at 10 MHz], > 40 dB [ at 1 GHz]
IP Rating IP 68 Certifications ISO9001 CE ROHS SGS



RAYMO RM-F series circular push pull connector Keying Codes Options

All Multipole body styles are mechanically coded.
Code 1 is the standard, but other codes can be requested

Fischer Dke Circular Push Pull Conenctors 102 103 104 Shell IP68 Circular Connectors 0

Raymo circular push pull circular connector
  1. Army, Navy, Air Force, Gendarmerie, Ministry of National Defense and Coast Guard
  2. Midcal equipments like Disposable equipment
  3. Test & measurement like Data acquisition
  4. Broadcast, like HD and SD cameras
  5. Energy, like Renewable energies
  6. Extreme, such as Sailboat racing
Raymo connectors Chooseing tips:

If you have purchased fischer connector and know the original model, please tell us. We will directly offer you our corresponding one.
If you don’t know much about the connector, please make choose according the following factors:

  1. the use of the environment, indoors or outdoors, waterproof or not;
  2. the panel hole size, to select the appropriate plug and socket of right dimension;
  3. the current-voltage, number of contact and the realization of the function, to determine the contact(cores)
  4. select the appropriate clamp diameter and sheath;
  5. according to the actual needs of different angles of the keys, to determine the keying (the standard keys as N)
Raymo DKE circular connector pictures
Fischer Dke Circular Push Pull Conenctors 102 103 104 Shell IP68 Circular Connectors 1
